• 300 W RGBALC LED array ellipsoidal

• Suitable for theatrical and studio applications

• High CRI for accurate colour rendering

• High refresh rate for flicker-free recordings

• 16-bit dimming with four preset curves

The Showtec Performer Profile 700 Q6 is a powerful 300 watt RGBALC LED array ellipsoidal with high CRI (>90) and whisper-quiet operation, suitable for theatrical and studio applications. The Profile 700 Q6 is the follow-up of the Profile 650 Q5 and features a 6-colour LED engine (RGBALC) with 16-bit 0 - 100 % dimming, using four selectable curves. Its internal engine guarantees precise colour temperatures from 1800 to 10,000 K with PWM frequencies of up to 25 kHz. DMX as well as RDM can be used to control the Performer Profile 700 Q6. Optional industry-standard fixed and zoom lenses allow proper projection of its light.

Specifications

Source

Light Source Type             LED

Light Source Quantity              1

Light Source Power                 300 W

LED Colour Type                      R, G, B, A, C, L

Light Source System                   6in1

Refresh Rate (Max.)                     25 kHz

Illuminance @ 2 m                   23862 lx

Illuminance @ 3 m                  10605 lx

Illuminance @ 5 m                   3818 lx

Luminous Flux (Total)                   10276 lm

Luminous Flux (Red)                  1289 lm

Luminous Flux (Green)                  2119 lm

Luminous Flux (Blue)                295 lm

Luminous Flux (Amber)                     1720 lm

Luminous Flux (Lime)                 3756 lm

Luminous Flux (Cyan)                 857 lm

CRI                 95

Minimum CCT                1800 K

Maximum CCT                 10000 K

Control and Programming

Control Mode                DMX, Master Slave, Stand Alone

DMX Channels               3, 7, 8, 10, 13, 20

Protocols                  DMX, RDM

Display                OLED

Dim Curve                  Linear, Square, I-Square, S-Curve

Dimmer Resolution                 16 bit

Dynamic Effects

Dimmer               0-100 %

Strobe               0-25 Hz

Electrical Specifications and Connections

Power Supply                100-240 V AC 50/60 Hz

Power Consumption               300 W

Power Connector In                  Power Pro True

Power Connector Out                 Power Pro True

DMX Connector                XLR 5P In/Out

DMX Connector In               XLR 5P

DMX Connector Out                 XLR 5P

Mechanical Specifications

Length (mm)              578 mm (22.756″)

Width (mm)                 301 mm (11.85″)

Height (mm)                   227 mm (8.937″)

Weight                 8 kg (17.637 lb)

IP Rating                 IP20 (indoor use only)

Housing                 Aluminium die-cast

Colour               Black

Product Properties

Cooling                 Convection/Axial fan

Rigging

Mounting Options             Bracket

Safety Attachment                  Yes

Safety Eyes              1

Thermal Specifications

Maximum Ambient Temperature            45 °C (113 °F)

Included Items

Included Cables          Power Pro True Cable
