• Mobile 8x 10 W RGBW LED Wash for temporary outdoor use (IP65)

• Operation up to 15 hours without charging

• 10° beam angle, optional beam shapers available

• Emergency backup mode and delayed output

• Tilt angle 180° adjustable

The Showtec Helix M1100 Q4 Mobile is a battery-powered, 8x 10 W RGBW LED Wash with IP65 rating, suitable for mobile indoor and temporary outdoor applications. Its 10° beam angle can be widened to a 20°, 40°, 15° x 60°, or 90° beam angle by using optionally available dedicated beam shapers. Equipped with a rechargeable lithium-ion battery, the Helix M1100 Q4 Mobile will operate up to 15 hours without charging. The tilt angle can be manually adjusted over 180° and the unit can be controlled via W-DMX (wireless), DMX, Master/Slave, Manual, and Auto mode, and has many built-in programs.

It has an emergency backup function, which switches the output to 4000 K white at maximum brightness in case the mains power drops. Its delayed output function allows you to program the unit and have it start later, saving precious battery runtime. This can be very helpful when setting up mid-day and having it turn on automatically at night. The Helix M1100 Q4 comes with a 1.5-metre powerCON TRUE1 cable, Quick-Lock bracket, and Safety Cable.

Specifications

Source

Light Source Type               LED

Light Source Quantity                  8

Light Source Power               10 W

LED Colour Type              RGBW

Refresh Rate                1200 Hz

Luminous Flux (Total)              8800 lm

Optical

Beam Angle (Horizontal)              10 °

Beam Angle (Vertical)             10 °

Wireless Specifications

Wireless Mode                G3, G4, G4s, G5

Reaction Time                  8 ms

Battery

Battery Type                  Lithium ion

Battery Voltage                     18.5 V

Capacity                    13 Ah

Runtime @Full                   8 h

Runtime Average                 15 h

Charging Time                 6 h

Control and Programming

Control Mode                 Auto, Built-in Program, DMX, Manual, Master Slave

DMX Channels                  4, 6, 10

Protocols               DMX, RDM

Wireless               Wireless DMX

Display                OLED, Touch

Dim Curve                  Linear, Square, I-Square, S-Curve

Dynamic Effects

Dimmer               0-100 %

Strobe                 0-20 Hz

Movement

Tilt Adjustment Up                   180 °

Electrical Specifications and Connections

Power Supply              100-240 V AC 50/60 Hz

Power Consumption                   75 W

Power Connector In                   powerCON TRUE1

Power Connector Out                   powerCON TRUE1

DMX Connector                     XLR 5P In/Out

DMX Connector In                     XLR 5P

DMX Connector Out               XLR 5P

Cable Length                 1.5 m

Mechanical Specifications

Width (mm)                 305 mm (12.008″)

Height (mm)              307 mm (12.087″)

Depth (mm)                126 mm (4.961″)

Weight                    7.9 kg (17.416 lb)

IP Rating                 IP65

Housing                Aluminium die-cast

Colour                Black

Product Properties

Cooling               Passive

Rigging

Mounting Options           Bracket, Clamp

Safety Attachment              Yes

Thermal Specifications

Maximum Ambient Temperature                 40 °C (104 °F)

Maximum Surface Temperature                    55 °C (131 °F)

Included Items

Included Cables               Power Pro True Cable

Included Rigging               Quick-Lock Bracket, Safety Cable
