• 24 multifunctional channel faders

• Up to 48 Scenes / Chases with max 999 steps

• Detachable frame

• Midi In & Out

• Remote black out/full on possibility

The Showmaster 24 MKII is a 2-banks 12 fader, 1-bank 24 fader mixing console, it controls DMX and has also the capability to be used with MIDI protocol to allow real-time programs. The Showmaster 24 MKII controls 2x 12 channels (single bank) or 24 channels. The Showmaster 24 MKII can program 48 scenes or chases of 999 steps or a loop with a total of 11988 steps. Programs can be run automatically or by external or internal music-input. It is also possible to control your lightshow by the built in MIDI-interface to allow a real-time live-show to your music.

Incl. side panels

Incl. 1 power adapter

Specifications

Control and Programming

Control Mode    Manual, MIDI, Sound

DMX Channels    24

Buttons    44

Chases   48

Faders    29

Memories    23976

Electrical Specifications and Connections

Power Supply    100-240 V AC 50/60 Hz (Power adapter)

Output voltage    12 V DC

Power Consumption    6 W

Power Connector In     Low Voltage DC plug

DMX Connector Out    XLR 3P

MIDI Connector   Yes

Audio Triggers    2

Power Adapter

Adapter type   AC-DC adapter

Input voltage    100-240 V AC, 50/60 Hz V

Output voltage    12 V DC

Mechanical Specifications

Width (mm)    530 mm (20.866″)

Depth (mm)    330 mm (12.992″)

Height (mm)    150 mm (5.906″)

Weight    4.8 kg (10.582 lb)

Rack Units    6 U

IP Rating   IP20 (indoor use only)

Housing     Metal, Plastic

Colour    Black, Gray

Product Properties

LED Indicators    Operation mode, Output level, Signal

Thermal Specifications

Maximum Ambient Temperature   40 °C (104 °F)

Included Items

Included Cables    None

Included Accessories     Adapter
